DOGMA F Sram RED ETAP AXS 12v Electro Orange – PINARELLO 2023

Description

*** DESCRIPTION ***

FRAME SET
FRAME
TorayCa T1100 1K Dream Carbon with Nanoalloy technology, TiCR™ cable routing, Italian BB, UCI approved
FORK
F Onda Fork with ForkFlap™, 1.5′ upper and lower steerer, Ultra Light Headset bearings
WEIGHT
disc brakes version: 6.9kg. weight in size 53, with dt swiss arc1400 50mm profile, w/o pedals and bottle cages/bottles
DRIVETRAIN
CRANKSET AND CHAINRINGS
SRAM Red ETAP AXS 12S
FRONT DERAILLEUR
SRAM Red ETAP AXS 12S
REAR DERAILLEUR
SRAM Red ETAP AXS 12S
CASSETTE
Sram Red XG-1290
CHAIN
sram red 12s
BOTTOM BRACKET
SRAM Red
BRAKES
FRONT BRAKE DISC
Sram Red 2 pistons caliper, 160mm rotor
REAR BRAKE DISC
Sram Red 2 pistons caliper, 160mm rotor
COCKPIT
INTEGRATED HANDLEBAR
MOST Talon Ultra Light
BAR TAPE
MOST Ultragrip Evo 3mm – Black
SADDLE
Most Lynx Ultrafast Superflow L Carbon Large 145mm
SEATPOST
Pinarello Aero seatpost with 3D printed titanium top seatclamp and bolts
SEAT CLAMP
Seatclamp Twinforce, titanium bolts
WHEELS AND TIRES
TYRES DISC
Pirelli P Zero Race 26mm – Black, 127 tpi aramid breaker. Max tyre size 28mm (width as measured)
WHEELSET DISC
PRINCETON Grit 4540
AXLES DISC
MOST Ultralight Custom Axle 12×100 & 12×142, Tool-free removal
